A p p e n d i x G A p p e n d i x G
Schematics
This appendix shows the schematic diagrams of the notebook.
G-1
CPU Board Connector
G-2 M1531 Bypass Capacitors
G-3 M1531
G-4 M1533
G-5 M1533 Configuration
G-6 Cache RAM & Tag RAM
G-7 16M EDO DRAM on board
G-8 DIMM Socket
G-9 Clock Generator CY2272
G-10 VGA Chip NM2097
G-11 LCD Interface
G-12 LCD Inverter
G-13 CRT Interface
G-14 HDD, media LED
G-15 CD-ROM, Internal FDD
G-16 USB
G-17 RTC, ROM
G-18 Keyboard Controller M38813
G-19 Fax/.Modem, Golden Finger
G-20 Super I/O 97338
G-21 Serial Port
G-22 Parallel Port, External FDD
G-23 Audio Chip YMF715 OPL3-SA3
G-24 OP-AMP
G-25 PCMCIA Controller OZ6833
G-26 TPS2206 & Socket
G-27 DC/DC, Charger, Battery Board
G-28 Skew Holes
