Disassembly and Unit Replacement

3-9

3.4

Removing the Hard Disk Drive

Follow these steps to remove the hard disk drive:

1.

Turn the computer over and locate the hard disk drive bay cover.

2.

Press the hard disk drive bay cover release and slide the cover out to remove it. Set aside the
cover.

3.

Pull the hard disk drive tab to remove the hard disk drive from the hard disk drive bay.

Figure 3-7

Removing the Hard Disk Drive

4.

Store the hard disk drive in an antistatic bag.

If you want to install a new hard disk drive, reverse the steps described above.
