QMXU/QMXU-HP Parts List
QMXLE/QMXLE-HP Parts List
1
2
3
4
5
6
7
See common parts (not shown) listed on page 9.
ITEM
NUMBER
ITEM
DESCRIPTION
1
QMX Curb Cap
2
QMXU Lifting Lug
3
QMXU Damper
4
QMXU Damper Stop
5
QMXU Windband
6
QMXU Discharge Guard (Optional)
See common parts (not shown) listed on page 9.
ITEM
NUMBER
ITEM
DESCRIPTION
1
QMXLE Mixing Box
2
QMXLE Curb Cap
3
QMXLE Middle Section
4
QMXLE Adapter Plate
5
QMXLE Stack Damper
6
QMXLE Windband
7
QMXLE Lifting Lug
