Qmxe/qmxe-hp parts list qmxs/qmxs-hp parts list – COOK QMX User Manual
Page 10
10
1
2
3
4
5
6
QMXE/QMXE-HP Parts List
QMXS/QMXS-HP Parts List
1
2
3
4
5
6
7
8
9
See common parts (not shown) listed on page 9.
ITEM
NUMBER
ITEM
DESCRIPTION
1
QMX Curb Cap
2
QMXE Birdscreen
3
QMXE Top Cap Post
4
QMXE Baffle Brace
5
QMXE Top Cap Extension (for Size 90 only)
6
QMXE Top Cap
See common parts (not shown) listed on page 9.
ITEM
NUMBER
ITEM
DESCRIPTION
1
QMX Curb Cap
2
QMXS Top Cap-Open
3
QMXS Upper Baffle Brace
4
QMXS Top Cap Post
5
QMXS Birdscreen
6
QMXS Top Cap
7
QMXS Lower Top Cap Post
8
QMXS Lower Baffle Brace
9
QMXS Adapter Plate
