Dimensions - direct drive, Service clearance- direct drive – COOK ERV User Manual
Page 5
5
Removable Plug
For Field
Electrical
Connections
(Bottom Panel)
Hinged Access to
All Internal Components
Front
Left View
K
E
J
D
F
Supply Air
Discharge
Return Air
Intake
G
M
L
Right View
F
G
M
L
K
E
J
D
B
Outdoor Air
Intake
C
Exhaust Air
Discharge
A
Right
H
Back
Left
All dimensions in inches.
Unit
Mounting
Rail Length
Housing
Width
Housing
Height
Exhaust Opening
Intake Opening
Mounting
Holes
J
K
L
M
A
B
C
D
E
F
G
H
ERV 500
52
22
23-13/16
7
5-11/16
7
12
50
4
5-5/16
1-1/2
4
ERV 1000
52
26
28-13/16
10-3/8
6-7/8
7
20
50
6-11/16 11-7/16
1-1/2
4
Dimensions - Direct Drive
Service Clearance
Service Clearance- Direct Drive
All dimensions in inches.
Unit
Service
Clearance
500
30
1000
35
