14
Manufactured under one or more of these patents. U.S. Patents: 5332944, 5361215, 5550753, 5559720, 5,883,459, 6253227, 6282370, 6590188, 6976052, 6965815, 7030343, 7,417, 834 b2,
Canadian Patent: 2342614, Australian patent: 2373248 other patents both foreign and domestic applied for and pending. All material copyright of Balboa Water Group.
4/22/13
240 Volt Residential Wiring Schematic with G.F.C.I.
Correct
Voltage
When Probes Are Placed Across
108V - 132V [1 - 3] [5 - 6] [5 - 10] [12 - 14] [13 - 14]
[2 - 3] [5 - 7] [5 - 11] [12 - 15] [13 - 15]
0v [3 - 4] [5 - 8] [5 - 9] [12 - 13]
108V - 132V [1 - 3] [5 - 6] [5 - 10] [12 - 14] [13 - 14]
[2 - 3] [5 - 7] [5 - 11] [12 - 15] [13 - 15]
Correct
Voltage
When Probes Are Placed Across
216V - 264V [1 - 2] [6 - 7] [10 - 11] [14 - 15]
[5 - 6]
[5 - 7] [12 - 14]
[12 - 15]
120 V
A
C
120 V
A
C
Neutral
Outside Ground Rod
ON
ON
ON
ON
ON
ON
ON
ON
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
ON
ON
ON
ON
ON
ON
ON
ON
House Breaker Box G.F.C.I Breaker Box
5
6
7
8
10
11
12
13
15
14
9
