120 Volt Residential Wiring Schematic with G.F.C.I.
120 V
A
C
120 V
A
C
Neutral
Outside Ground Rod
ON
ON
ON
ON
ON
ON
ON
ON
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
ON
ON
ON
ON
ON
ON
ON
ON
House Breaker Box G.F.C.I Breaker Box
4
5
6
8
9
10
11
7
Correct
Voltage
When Probes Are Placed Across
108V - 132V [1 - 2} [1 - 3] [4 - 5] [4 - 8] [5 - 6]
[5 - 9] [6 - 8] [7 - 8] [9 - 11] [10 - 11]
0v [2 - 3] [4 - 6] [4 - 7] [5 - 8] [9-10]
108V - 132V [1 - 2} [1 - 3] [4 - 5] [4 - 8] [5 - 6]
[5 - 9] [6 - 8] [7 - 8] [9 - 11] [10 - 11]
Correct
Voltage
When Probes Are Placed Across
