Swiftech MCW55 User Manual
Page 4
Install your block onto the graphics card, as shown in Figure 1 or Figure 2 (p.1) according to your application. A “finger –tight” lock is
always sufficient when tightening the spring retention assemblies. Over-tightening will squish the nylon screw spacer body, and result in
uneven pressure over the GPU.
4.
Re-install the graphics card in the AGP or PCI slot, connect the tubes to the rest of the circuit, and proceed with filling and bleeding
the cooling circuit.
5.
Type of Coolant: For best performance, use 95% distilled water, and 5% Swiftech brand “HydrX” corrosion inhibitor (available here:
, under the “accessories” section).
6.
Final inspection: Once the installation is completed, it is always a good idea to test the circuit for leaks, prior to powering up the
computer. Troubleshooting help is available on our web site at
or by calling customer support at 562-595-8009.
Removal of the tubing
:
1.
Remove the red safety clips
2.
In quick-connect fittings, the collets contain a ring of shark-like teeth that prevent the tubing from coming out of the fitting. In order to
release the ring of teeth and allow the tube to come out, the collet needs to be pushed squarely flat against the face of the water-block.
To make sure that the collet remains completely flat against the face of the water-block while the tube is being pulled out, use a simple
½” flat wrench. Then holding the tube with 3 fingers as shown below, push with your thumb against the face of the wrench, this will pull
the tube out of the fitting. This simple leverage effect works great, and avoids many frustrations!
IMPORTANT MAINTENANCE PRECAUTIONS:
If you need to disassemble the waterblock for cleaning purposes, it is extremely important to exert the utmost care in re-fastening the copper
base-plate to the housing. Since an o-ring assures the seal between housing and base-plate, little pressure is needed to guarantee a good
seal between these two components. Fasten the four screws finger-tight only, or you take the risk of stripping the thread of the plastic
housing. Note that no warranty claims will be accepted for stripped threads in the housing.
IMPORTANT DISCLOSURES
While all efforts have been made to provide the most comprehensive tutorial possible, Swiftech assumes no liability expressed or implied for any
damage(s) occurring to your components as a result of using Swiftech cooling products, either due to mistake or omission on our part in the above
instructions, or due to failure or defect in the Swiftech cooling products.
WARRANTY
Our products are guaranteed for 12 months from the date of delivery to the final user against defects in materials or workmanship. During this period,
they will be repaired or have parts replaced provided that: (I) the product is returned to the agent from which it was purchased; (II) the product has
been purchased by the end user and not used for hire purposes; (III) the product has not been misused
(*)
, handled carelessly, or other than in
accordance with any instructions provided with respect to its use. This guarantee does not confer rights other than those expressly set out above and
does not cover any claims for consequential loss or damage. This guarantee is offered as an extra benefit and does not affect your statutory rights as a
consumer.
Copyright Swiftech 2005 – Subject to revision without notice - Revision date: 9-15-05
Swiftech Inc., 1703 E. 28
th
St., Signal Hill, CA 90755 T. (562) 595-8009 F. (562) 595-8769
Page 4 of 2
