Swiftech MCW6000 2 PX User Manual

Page 3

Figure 3

Water-block installation

The MCW6000 series can be installed using two different methods (also see figure 1 and 2):

Using the spring-loaded screws and standoffs included with the water-block (fig. 1), or

Using the plastic retention frames and spring slips included with most motherboards (fig. 2)

You may use either method at your convenience. For installation with our own spring loaded
screws, follow the instructions below. For installation with Intel’s spring clips, follow the instructions
included in your motherboard manual.

Installation with spring loaded screws:

Remove the motherboard from the chassis, and remove the stock retention plastic frames to expose
the mounting holes.

Install the standoffs though the holes, using fiber washers and locknuts as shown in figure 1.

Tighten the standoffs as shown figure 3, using a ¼” socket tool to drive the standoff, and a
small pair of pliers to prevent the locknut from spinning. Torque value should not to exceed 16
in. lbs. In other words just tight, without excessive torque, otherwise the standoff stem may
snap.

Tighten the spring-loaded screws in a crisscross pattern until the screws bottom out into the
standoff. Once there, do not attempt to lock the screws any further, or they will jam into the
standoff, and could prove difficult to remove if you ever need to uninstall the heatsink.

Water-block installation is now complete!

Connecting the water-block(s) to the cooling circuit:

Carefully identify the direction of the flow in your circuit. For the MCW6000 to operate properly, the fitting
located at the center of the water-block MUST BE USED AS THE INLET. In multi-processor environments,
connect the two blocks in series: For example: pump discharge to inlet of processor 1, discharge of
processor 1 to inlet of processor 2, and discharge of processor 2 to radiator.

Attaching the tubes:

The MCW6000™ series ship with worm-drive type hose clamps. Secure the tubes as shown in the picture to
the right (shown below with an AMD bracket), and tighten firmly.

5. Type

Coolant:

Being entirely made of copper, the MCW6000™ series may be used with pure water, and do not necessitate
the use of anti-corrosion agents. The use of an algaecide is nonetheless recommended in any liquid cooling
system, and our HydrX™ additive also performs such function.

6.

Final inspection

Once the installation is completed, it is always a good idea to test the circuit for leaks, prior to powering up
the computer. Do not test the water-block using city water pressure. This will bow the top of the housing
and render the block unusable (and will void your warranty). Maximum pressure allowable for testing is
25 psi (1.7 bar)

Troubleshooting help is available on our web site at

www.swiftnets.com

, or by calling customer support at

562-595-8009.

Figure 4

Tubes attached with the
included worm-drive clamps
