Allied Telesis AR400 SERIES Software Release 2.7.1 - Manual (Page 114)

114 AR400 Series Router User Guide
Software Release 2.7.1
C613-02021-00 REV F
local (i.e. via eth0) on one router, should also be visible on the other router, via the PPP
link.
Test that a workstation on the Remote Office LAN can login to the file server
on the Head Office LAN.
4. Save the Configuration
Save the new dynamic configuration as a script, by entering the command:
CREATE CONFIG=IPXCONF.SCP
To add an IPX circuit over a VLAN
1. Define the IPX interface name
To create IPX circuit 1 with the Novell network number 129 over the admin
VLAN, enter the command:
ADD IPX CIRC=1 INTERFACE=vlan11 NETWORK=129 ENCAP=802.3
2. Show the configuration
Show the new configuration by entering the command:
SHOW IPX CIRCUIT
The display should look like that shown in Figure 17. To interpret output from
the SHOW IPX CIRCUIT command see the Novell IPX chapter in the Software
Reference.
