Chapter 1: Overview
24
Back-to-Back
Topology
Figure 9 shows a back-to-back topology using two AT-CV1200 chassis
with two AT-CM202 line cards, with one line card in each chassis used to
interconnect two small networks.
The media converters themselves are connected together through
100Base fiber optic ports on AT-CM202 line cards.
Network 1 has an AT-8350GB switch connected to the 10/100Base-TX
port on the AT-CM202 line card in the first AT-CV1200 media
converter.
Network 2 has an AT-8524M switch connected to the 10/100Base-TX
port on the AT-CM202 line card in the second AT-CV1200 media
converter.
Figure 9. Back-to-Back Network Topology
