Chapter 1: Overview
18
AT-CV5M0x Management Card
The AT-CV5M0x Management Card provides a CPU subsystem for the
Allied Telesis Converteon Series chassis such as the AT-CV5000 and the
AT-CV120x. The AT-CV5M0x Management Card is shipped with the
management software preinstalled that allows you to configure and
monitor the status of the media converter line cards in the chassis.
Note
The AT-CV120x supports only one AT-CV5M0x Management Card
at a time.
The AT-CV5M01 Management Card is shown in Figure 3.
Figure 3. AT-CV5M01 Management Card
For more information about the AT-CV5M0x Management Card, refer to
the documentation that is shipped with the product
258
AT-CV5M01
PWR R
DY F LT
CPU RESET
LK A T FD
