Appendix A: Technical Specifications
86
RS-232 Terminal Port Pinouts
Table 15 lists the pin signals on the RS-232 terminal port.
Table 15. RS-232 Terminal Port Pin Signals
Pin
Signal
1
Data Carrier Detect
2
Transmit Data
3
Receive Data
4
Data Set Ready
5
Ground
6
Data Terminal Ready
7
Clear to Send
8
Request to Send
9
Ring Indicator
