AT-8500 Series Layer 2+ Fast Ethernet Switches Installation Guide
17
Model Descriptions
AT-8516F/SC
The AT-8516F/SC switch has 16 100Base-FX fiber optic ports with dual
SC connectors. The ports operate at 100 Mbps, half- or full-duplex mode,
and have a maximum operating distance of 2 kilometers (1.24 miles) or
412 meters (1,360 feet), depending on the duplex mode, using 50/125 or
62.5/125 micron (core/cladding) multimode fiber optic cable.
Figure 1 illustrates the front panel of the AT-8516F/SC switch.
Figure 1. AT-8516F/SC Switch Front and Back Panels
FAULT
RPS
MASTER
PWR
STATUS
18 17
D/C
L/A
D/C
L/A
D/C
L/A
D/C
L/A
D/C
L/A
D/C
L/A
D/C
L/A
D/C
L/A
D/C
L/A
D/C
L/A
D/C
L/A
D/C
L/A
D/C
L/A
D/C
L/A
D/C
L/A
D/C
L/A
LINK / ACTIVITY HALF DUP/ COL FULL DUP L/A D/C PORT ACTIVITY
AT-8516F/SC
100Base-FX Fast Ethernet Switch
RS-232 TERMINAL PORT
1 TX RX
9 TX RX
2 TX RX
10 TX RX
3 TX RX
11 TX RX
4 TX RX
12 TX RX
5 TX RX
13 TX RX
6 TX RX
14 TX RX
7 TX RX
15 TX RX
8 TX RX
16 TX RX
RS-232 Module Expansion Slots
100Base-FX Ports
Terminal Port
System LEDs Port LEDs
100-240VA C ~
RPS INPUT
RPS Connector AC Power Connector
