AT-8500 Series Layer 2+ Fast Ethernet Switches Installation Guide
45
Figure 11 illustrates a network of three AT-8524M Fast Ethernet switches.
The workstations and servers on the network are connected either directly
to a switch or indirectly through an Ethernet hub. The switches themselves
are connected together through 1000Base fiber optic ports on AT-A45/SC
expansion modules, creating a high-speed backbone.
Figure 11. Mixed Topology
AT-8524M
AT-8524M
1
5
4
3
2
6
7
8
1
5
4
3
2
6
7
8
AT-8524M
AT-8524M Fast
Ethernet Switch
AT-8524M Fast
Ethernet Switch
AT-8524M Fast
Ethernet Switch
Legend
10 Mbps
100 Mbps
1000 Mbps
Fiber Optic
