Rj-45 1000base-t connector pinouts – Allied Telesis AT-GS950/8 User Manual
Page 51
AT-GS950/8 Gigabit Ethernet WebSmart Switch Installation Guide
51
Table 8 lists the RJ-45 connector pins and their signals when a
1000Base-T port is operating at 1000 Mbps.
Table 8. RJ-45 1000Base-T Connector Pinouts
Pin
Pair
Signal
1
1
TX and RX+
2
1
TX and RX-
3
2
TX and RX+
4
3
TX and RX+
5
3
TX and RX-
6
2
TX and RX-
7
4
TX and RX+
8
4
TX and RX-
