AT-GS950/8 Gigabit Ethernet WebSmart Switch Installation Guide

39

4. Slide the SFP transceiver into an SFP slot on the switch, as shown in

Figure 14.

Figure 14. Inserting the SFP Transceiver

5. Repeat steps 2 through 4 if you are installing another SFP transceiver.

Note

SFP transceivers are dust sensitive. When a fiber optic cable is not
installed, or when you store the SFP transceiver, keep the plug in
the optical bores. When you do remove the plug, keep it for future
use.

Note

Unnecessary removal and insertion of an SFP transceiver can lead
to premature failure.

For information about cabling the SFP transceiver, consult the
documentation that was shipped with the SFP transceiver.
