Front and back panels, Figure 1. front and back panels – Allied Telesis AT-GS950/8 User Manual
Page 17
AT-GS950/8 Gigabit Ethernet WebSmart Switch Installation Guide
17
Front and Back Panels
Figure 1 shows the front and back panels of the AT-GS950/8 switch.
Figure 1. Front and Back Panels
912
10/100/1000Base-T
Twisted Pair Ports
SFP Ports
913
100-240VAC
DEFAULT WEB MANAGEMENT PARAMETERS
IP Address: 192.168.1.1
Subnet Mask: 255.255.255.0
Port LEDs
System (Power) LED
Recessed Reset Button
SFP Port LEDs
AC Power Connector
