Chapter 2: Installation
34
Mounting the Switch on a Wall
To mount the AT-GS950/8 switch on a wall, perform the following
procedure:
1. If the rubber feet are attached, turn over the switch and remove the
rubber feet using a flat-head screwdriver.
2. Select a wall location for the device.
3. Choose one of the following:
ˆ For drywall installation, drill two 1/8-inch holes that are 5 3/8 inches
apart. Insert the plastic anchors. Tap the anchors flush with the
wall.
ˆ For installation into a wood surface, two 1/8-inch holes that are
5 3/8 inches apart.
Note
Plastic anchors are not used for installation into a wood surface.
4. Insert two stainless steel screws that are included with the switch as
shown in Figure 7.
Figure 7. Installing the Plastic Anchors and Screws
5. Tighten the screws, leaving 1/4-inch of the thread exposed.
