6.6 AT-9900 Series
Topics:
• Classifiers
• Flow Groups
• Traffic Classes
• Policies
• Ports
• Scheduling
• Quick Setup
• Notes
6.6.1 Classifiers
6.6.1.1 QoS Information Window
Column Name Description
Classifier ID Lists the Rule ID of packet-matching rules available
6.6.1.2 Add/Modify Classifier
Property Name Description Valid Values
Rule ID
(cannot be
modified)
Uniquely identifies the packet-
matching rule
Range: 1-9999
Source MAC
Address Specifies the source MAC address
of the packet. This can be set by entering a MAC
address string using the following
format:
• XX-XX-XX-XX-XX-XX
This can also be set to "any" or
"dhcpsnooping".
Destination MAC
Address
This parameter specifies the
destination MAC address of the
packet.
This can be set by entering a MAC
address string using the following
format:
• XX-XX-XX-XX-XX-XX
This can also be set to "any".
Source MAC
Address Mask
Specifies the masks to be used on
the Source MAC Address. When a
bit is set to 1 in the mask, the value
of the bit at the same position in the
This can be set by entering a MAC
address string using the following
format:
