6.1.3 Scheduling
Setting Description Value
Scheduling Configures the number of expedite
queues. It is used to specify the
scheduling method to use.
• Strict Priority - higher
priority queues are emptied
before any packets are
transmitted from lower
priority queues
• Weighted Priority - packets
are transmitted from all
queues in a round-robin
fashion based on the queue
weights
6.1.4 CoS Priority
Column Name Description Value
Class of Service
(cannot be
modified)
Lists the CoS values available Range: 0-7
Queue Specifies the queue number to
which the CoS value is mapped
Range: 1-4
6.1.5 DSCP Priority
Column Name Description Value
DSCP
(cannot be
modified)
Lists the DSCP values available Range: 0-63
Queue Specifies the queue number to
which the DSCP value is mapped
Range: 1-4
6.1.6 Bandwidth
Column Name Description Value
Interface
(cannot be
modified)
Lists the interfaces (ports and
channels) available The available interfaces will depend
on the device model and
configuration.
• standalone - e1, e2..en
• stacked - 1/e1, 1/e2..1/en,
2/e1, 2/e2..s/en
• channels - ch1, ch2..chn
where:
• n = port/channel number
• s = stack id
Ingress Status Enables/Disables the Rate Limit field • enabled
• disabled
