Appendix A

Technical Specifications

Physical Specifications

Dimensions (W x D x H):

440 mm x 257 mm x 43.2 mm
(17.32 in x 10.12 in x 1.70 in)

Weight:

4.133 kg (9.11 lbs)

Environmental Specifications

Operating Temperature:

-0° C to 40° C (14° F to 122° F)

Storage Temperature:

-25° C to 70° C (-40° F to 158° F)

Operating Humidity:

5% to 90% non-condensing

Storage Humidity:

5% to 95% non-condensing

Operating Altitude Range:

Up to 3,000 m (9,843 ft)

Power Specifications

AC Voltage/Frequency Requirements:

100 - 240 VAC, 50/60 Hz

AC Input Power Consumption:

130 W Maximum

Available Power over Ethernet:

100 W @ 48 VDC

IEEE 802.3af Class 3 (15.4 W):

Max 6 ports

IEEE 802.3af Class 2 (7.3 W):

Max 12 ports

IEEE 802.3af Mode:

Alternative A (MDI)
