Chapter 1: Overview
24
10/100Base-T
Non-POE Port
LEDs
Ports 13 through 24 each have two LEDs as shown in Figure 5 and
described in Table 5.
.
Figure 5. 10/100Base-T Non-PoE Port LEDs (Port 13 - 24)
Table 5. 10/100Base-T Non-PoE Port LEDs (Port 13 - 24) Description
LED State Description
L/A
Solid Green A valid 10/100M link has been established.
Blinking
Green The port is transmitting or receiving data.
Off No link is established on the port.
100M
Solid Green A valid 100 Mbps link is established between
the port and the end node.
Off A valid 10 Mbps link is established between
the port and the end node.
