AT-FS750/24POE Fast Ethernet WebSmart Switch Installation Guide
45
4. Mount the switch on a 19-inch rack, as shown in Figure 13.
Note
The rack mount screws are not provided.
Figure 13. Mounting the Switch on the Rack
5. If you plan to install SFP transceiver modules, go to the next step at
“Installing an SFP Transceiver” on page 46. Otherwise, your next step
will be “Cabling and Powering On the Switch” on page 48.
1721
24 Port 10/100 M
bps WebSm
art Sw
itch
with 12 PO
E and 2 Co
mbo SFP
Ports
