Powering on the switch – Allied Telesis AT-FS750/24POE User Manual
Page 50
Chapter 2: Installation
50
2. Connect the fiber optic cable to the SFP port, as shown in Figure 18.
Figure 18. Connecting the Fiber Optic Cable
Powering On the
Switch
To power on the switch, perform the following procedure:
1. Plug the power cord into the AC power connector on the back of the
switch, as shown in Figure 19.
Figure 19. Plugging in the AC Power Cord
2. Plug the other end of the power cord into a wall outlet.
1725
Warning: Power cord is used as a disconnection device. To de-
energize equipment, disconnect the power cord.
E3
100-240V
AC~
50-60Hz
1727
