AT-FS750/24POE Fast Ethernet WebSmart Switch Installation Guide
19
Front and Back Panels
Figure 1 illustrates the front and back panels of the AT-FS750/24POE Fast
Ethernet WebSmart Switch.
Figure 1. AT-FS750/24POE Front and Back Panels
POWER
POE
SYSTEM
24 Port 10/100 Mbps WebSmart Switch
with 12 POE and 2 Combo SFP Ports
1714
10/100Base Twisted Pair Ports
Port LEDs
Uplink Combo Ports
System LEDs
eco-friendly Switch
1715
100-240VAC~
50-60Hz
AC Power
