Page 38
Chapter : Technical Specifications
38
Immunity:
EN55024
Electrical Safety:
UL 60950-1 (
C
UL
US
)
EN60950-1 (TUV)
CE
Laser Safety:
EN60825-1
Environmental Compliance
Eu-RoHS compliant: Yes
China-RoHS compliant: Yes
WEEE: Yes
RJ-45 Twisted-Pair Port Specifications
Cable
Requirements
The cable requirements of the
RJ-45 twisted-pair
port are given in Table 5.
Table 5. Twisted-Pair Cable Requirements for the 100Base-TX Ports
Cable Type
100Mbps
Standard TIA/EIA 568-A-compliant
Category 5 or TIA/EIA 568-B-compliant
Enhanced Category 5 (Cat 5e) shielded
or unshielded cabling with 100 ohm
impedance and a frequency of 100
MHz.
Yes
Standard TIA/EIA 568-B-compliant
Category 6 or 6a shielded cabling.
Yes
