Chapter 2: Installation
30
6. Select an empty, non-shared PCI slot and remove the faceplate. See
Figure 8.
Figure 8. Removing the Faceplate From PCI Slot
Note
Keep the faceplate in a safe place. You may need it for future use.
7. On the inside of the computer chassis, push the media converter card
until it is firmly seated in the appropriate PCI slot by applying even
pressure at both corners of the card. See Figure 9. Make sure the card
is securely seated.
Figure 9. Inserting the Adapter with a High-profile Bracket
Caution
Do not use excessive force when seating the card, because this
may damage the system or the adapter. If the card resists seating,
remove it from the system, realign it, and try again.
