PC 6170 User’s Manual
TTL signal asserted (high state): greater than 4.75V while sourcing
500uA.
High state output impedance: less or equal to 1Kohm from output to
common.
P O W E R G OOD @ 11 5 / 2 3 0V ,FULL LOA D 100 –500mSec.
P O WER FAIL @ 1 15 / 2 3 0 V , FULL LOAD 1 mSec. minimum
EFFICIENCY
115 V A C @Ful l Load 68% minimum
230 VAC @F u ll Load 68% minimum
ENVIRONMENTAL REQUIREMENTS
The power supply will be compliant with each item in this specification
for the following Environmental conditions.
TEMPERATURE RANGE
Op e r a t i n g 0 to +50 deg. C
St o r ag e -20 to +80 deg. C
HUMIDITY
Op e r a t i n g 5 –95% RH, Non-condensing
St o r ag e 5 –95% RH, Non-condensing
VIBRATION
The subject power supplies will withstand the following imposed
conditions without experiencing
non-recoverable failure or deviation from specified output
characteristics.
Vibration Operating – Sine wave excited, 0.5 G maximum acceleration,
10-250 Hz swept at one
octave / min. Fifteen minute dwell at all resonant points, where
resonance is defined as those
exciting frequencies at which the device under test experiences
excursions two times large than
66 Power Supply Specification
