PC 6170 User’s Manual

LOAD CAPACITY SPECIFICATIONS

The cross regulation defined as follows, the voltage regulation limits
DC include DC Output ripple & noise.

LOAD S T M

+3.3V +5V

+12V

-12V

ALL MAX

HHHH

4.5A

9.0A

9.0A

0.8A

+5V MAX

other MIN

+3.3V MAX

other MIN

+12V MAX

other MIN

LHLL

0.3A 12.0 A

1.5A

0.0A

HLLL

16.8 A

0.3 A

1.5A

0.0A

LLHL

0.3 A

0.3 A

10.0A

0.0A

ALL MIN

LLLL

0.3 A

0.3 A

1.5A

0.0A

HOLD-UP TIME (@FULL LOAD)

115V / 60Hz : 17 mSec. Minimum.

230V / 50Hz : 17 mSec. Minimum.

OUTPUT RISE TIME

(10% TO 90% OF FINAL OUTPUT VALUE, @FULL LOAD)

115V-rms or 230V-rms

+ 5Vdc : 20ms Maximum

OVER VOLTAGE PROTECTION

+5Vdc output: +5.7Vdc minimum,

+ 6.5Vdc maximum

+12Vdc output: +13.3Vdc minimum,

+15.6Vdc maximum

+ 3.3Vdc output: +3.7Vdc minimum,

+ 4.5Vdc maximum

64

Power Supply Specification
