PC 6170 User’s Manual
1/2/4/6/8/10/20/
30/40 Min/1 Hr
HDD Power Down
Defines the continuous idle time before the
system entering SUSPEND mode.
If any item defi ned in (J) i s enabled & active,
S USPEND timer will be reloaded
After the selected period of drive inactivity (1 to 15 minutes), the hard
disk drive powers down while all other devices remain active. The default
value is “Disabled”.
Disabled HDD’s motor will not power OFF.
1/2/3/4/5/6/7/8/
9/10/11/12/13/1
4/15 Min
Throttle Duty Cy cle
Defines the continuous HDD idle time before
the HDD enters power saving mode (motor OFF)
When the system enters Doze mode, the CPU clock runs only part of the
time. You may select the percent of time that the clock runs. The default
value is “62.5%”.
VGA Active Monitor
When Enabled, any video activity restarts the global timer for Standby
mode. The default value is “Enabled”.
Soft-Off by PWR-BTTN
This option only works with systems using an ATX power supply. It also
allows the user to define which type of soft power OFF sequence the
system will follow. The default value is “Instant-Off”.
Instant-Off
Delay 4 Sec.
Power On by Ring
This option follows the conventional manner system s
perform when power is turned OFF. Instant-Off i s a soft
power OFF sequence requiring onl y the switching of the
power supply button to OFF
Upon turning OFF system from the power switch, this
option will delay the complete system power OFF
sequence by approximatel y 4 seconds. Within this
delay period, system will temporarily enter into
Suspend M ode enabling you to restart the system at
once.
This option allows the system to resume or wake up upon detecting any
ring signals coming from an installed modem. The default value is
“Enabled”.
IRQ 8 Break Suspend
You can turn on or off monitoring of IRQ8 (the Real Time Clock) so it
SBC83810 BIOS Setup 55
