PC 6170 User’s Manual
I/O System
„ Standard I/O:
− 3 x serial ports with power; 2 x RS-232, 1 x
RS-232/422/485 jumper selectable
− 1 x parallel port, SPP/EPP/ECP
− 1 x PS/2 for Keyboard Interface
−
1 x PS/2 for Mouse Interface
−
3 x USB Ports 2.0 compliant(1 at rear; 2 at front panel)
−
1 x 1 5 pin(female) for VGA output
„ Ethernet:
Realtek 8100C PCI Bus 10/100M Base-T
Wake On LAN (via ATX power supply)
Equipped with RJ-45 interface
Realtek RTL8110S for 10/100/1000Base-T
„ Audio:
Realtek ALC202A AC’97 codec audio
Amplify for speaker-out with 2.5 W for each channel
MIC-in, Line-in, Line-out/Speaker-out (jumper
selectable)
„ Onboard IDE:
4 channels up to 6 devices (2 parallel ATA-100 and 2
serial ATA-150)
RATA-100 as PIO Mode 0-4, DMA Mode 0-2 and Ultra
DMA/33/66/100
„ Onboard Serial ATA:
Independent DMA operation on two ports.
Data transfer rate up to 150 Mbyte/s
Altemate Device IDE and RAID Class Code option for
support of Soft RAID.
Introduction 3
