The control panel
50 Instruction manual BFC
7
gis
• Buttons for UP , and DOWN ;
• Enter: ;
• Reset button: .
The ^ arrows and È indicate that you can scroll up
and/or down. Use the buttons and to scroll.
The cursor » points to the option to be activated. In the
display as shown in the figure, you can scroll through
the main menu.
The main menu comprises: OFF, ON,
WEEK PROGRAM
, EXTRA PERIOD and
SETTINGS . You have to scroll down further to see the
options EXTRA PERIOD and SETTINGS.
The selected option is confirmed using
.
Pressing the button takes you back one page
in a menu and discards all options selected in the
current menu.
Note
The
button is also used to reset the
appliance following an error.
7.6 PC connection
The PC connection is solely intended to enable
technicians from A.O. Smith to display the status and
history of the appliance. These details can be
important for troubleshooting and/or responding to
complaints.
MENU
OFF
^»ON
È WEEK PROGRAM
EXTRA PERIOD
SETTINGS
