Installation
30 Instruction manual BFC
3
is
Concentric wall flue terminal specifications C13
Concentric roof flue terminal specifications C33
Specification Description
Wall flue terminal set:
•
1X Wall flue terminal (incl. wall flange
& clamping ring)
• 1X Pipe 500mm
• 1X Bend 90°
Art. No. BFC 28
BFC 30-50-60 0302 515
1
0302 504 1
Construction Concentric
Manufacturer Muelink & Grol
Model M2000 MDV SEC
Pipe material Construction Concentric
Flue Thick-walled aluminium with lip ring seal
Air supply Thin-walled galvanised sheet steel
Pipe diameters Flue BFC 28
BFC 30-50-60 Ø 80 mm
Ø 100 mm
Air supply BFC 28
BFC 30-50-60 Ø 125 mm
Ø 150 mm
(1) No other wall flue terminal is permitted. Use this item number to order the wall conduit set from supplier,
manufacturer or wholesaler.
Specification Description
Roof flue terminal set:
•
1X Wall flue terminal (incl. clamping
ring)
• 1X Pipe 1000mm
• 1 X Mounting flange
Art. No. BFC 28
BFC 30-50-60 0305 042 1
0304 423
1
Construction Concentric
Manufacturer Muelink & Grol
Model M2000 DDV HR-C
Pipe material Construction Concentric
Flue Thick-walled aluminium with lip ring seal
Air supply Thin-walled galvanised sheet steel
Pipe diameters Flue BFC 28
BFC 30-50-60 Ø 80 mm
Ø 100 mm
Air supply BFC 28
BFC 30-50-60 Ø 125mm
Ø 150 mm
(1) No other wall flue terminal is permitted. Use this item number to order the wall conduit set from supplier,
manufacturer or wholesaler.
