104
Chapter 4.
Settings and Upgrade
Upgrading Memory
(Optional)
3
Remove the screw on the memory compartment cover at the
bottom of the computer using a screw driver.
Fixing Screw
Memory
Compartment Cover
4
Insert a new memory module into the memory slot at an
angle of approximately 30 degrees aligning it to the angle of
the memory slot.
Memory Slot
5
Push the memory module down so that it is completely fixed.
If the memory does not fit easily, push the memory module
down while pulling the memory module latches outward.
Memory Module Latches
6
Close the memory compartment cover and fasten the screw.
7
Connect the AC adapter and press the power button to turn
the computer on.
If you do not connect the AC adapter, the computer will not
be turned on even if you press the power button.
