Connecting the ethernet interfaces, Figure 3, Inch rackmount illustration – ADTRAN TRACER 5045 User Manual
Page 38: Figure 3. 23-inch rackmount illustration
Section 4 Network Turnup Procedure
TRACER 5045 System Manual
38
© 2004 ADTRAN, Inc.
612805045L1-1B
Figure 3. 23-inch Rackmount Illustration
8.
CONNECTING THE ETHERNET INTERFACES
The physical Ethernet interfaces are provided using four RJ-48C jacks. Ethernet cables are not supplied
with your shipment. Connect any standard Ethernet device to one of the switch ports located on the rear of
the unit.
TRACER 5045
TRACER 4206
LAN
3
2
1
4
WAN
