HOT AISLE CONTAINMENT
Page 3 of 23
Installation Instructions
Containment Door Assembly Sequence (2/2) :
3. Seal the Containment Frame assembly to the side wall of the Cabinet (Fig. 3)
4. After sealed by the Foam tape, There should be ¼” (6.35mm) gap between the
inner wall on the door and side of the first cabinet (Fig. 3).
Fig.3
¼” gap between the Inner
wall on the Door and the
side of the First cabinet.
Foam Seal
Cabinet
Containment
Door
