HOT AISLE CONTAINMENT
Page 14 of 23
Installation Instructions
Header Panel Assembly Sequence (2/5) :
19. First assemble Header panel (fig. 16).
Universal
Bulb seal
Polycarbonate panels
Step: 2
Step: 3
H = cabinet Top to
bottom of the
Containment POD.
L= Cabinet
Width
Universal Bulb seal
Polycarbonate panels
1 inch
Gap should be
maintained.
1 inch
L= Cabinet
Width
Fig. 16
Header Panel
assembly
