HOT AISLE CONTAINMENT
Page 2 of 23
Installation Instructions
Containment Door Assembly Sequence (1/2) :
Part Identification:
WARNING: Until the frame assembly is attached to the cabinet,
the frame must be held up in place by at least one person.
1. Prior to Installing the Doors, place a strip of foam sealing tape on
either the door or the Cabinet (Fig.1).
2. Position the Containment door at an angle position (Fig.2).
Double Sliding Containment Door
2 each
Foam Sealing Tape
Back side view of
Containment Door
Fig.1
Foam
Seal
Fig.2
