HOT AISLE CONTAINMENT
Page 22 of 23
Installation Instructions
Filler Panel Assembly Sequence(2/3):
23. Insert Polycarbonate sheet into the bulb seal (fig. 22).
24. Similarly assemble the extrusion and seal on other side (fig. 23).
Polycarbonate
panel
Universal bulb
seal
Filler panel
extrusion
Universal bulb
seal
Filler panel
extrusion
Polycarbonate
panel
Top View
(Assembled Condition)
Top View
(Assembled Condition)
Fig. 22
Fig. 23
