HOT AISLE CONTAINMENT
Page 16 of 23
Installation Instructions
Header Panel Assembly Sequence (4/5) :
Containment
Extrusion
Polycarbonate panel
installed - as seen from
inside of containment.
Universal bulb
seal on cabinet
Top panel
Cross section view of header
panel assembly on to the
cabinet with Containment
Structure
Polycarbonate
Clip goes
directly into
extrusion
Polycarbonate
Panels
Inside
Containment
Universal bulb
seal
Cabinet
Fig. 18
