26 | SAMLEX AMERICA INC.
PARAMeteR
Sealed (Gel Cell) Sealed (AGm) flooded
12V 24V 12V 24V 12V 24V
bulk Charge Current
equal to Instantaneous Short Circuit Current Isc of
the PV Panel(s) / Maximum 10A
Absorption (boost) Voltage 14.2V 28.4V 14.4V 28.8V 14.6V 29.2V
Absorption (boost) Duration 2 Hrs 2 Hrs 2 Hrs
float Voltage 13.8V 27.6V 13.8V 27.6V 13.8V 27.6V
equalization Voltage Not equalized 14.6V 29.2V 14.8V 29.6V
equalization Duration Not equalized 2 Hrs 2 Hrs
Automatic reset to bulk 13.2V 26.4V 13.2V 26.4V 13.2V 26.4V
Charging Limit Voltage
[Disconnect PV Panel(s)]
15.5V 31.0V 15.5V 31.0V 15.5V 31V
over Voltage Disconnect:
Disconnect PV Panel(s) and Load
Indication on Status LeD “PV”:
Green - fast flashing
16.0V 32.0V 16.0V 32.0V 16.0V 32.0V
Activate Under Voltage Warning
Signaling - Status LeD “bATT” turns
orange from Green
12.0V 24.0V 12.0V 24.0V 12.0V 24.0V
reset Under Voltage Warning
Signaling - Status LeD “bATT”
goes back to Green from orange
12.2V 24.4V 12.2V 24.4V 12.2V 24.4V
Activate Protection Against over
Discharge by disconnecting Load -
Status LeD “bATT” turns
red from Green
11.1V 22.2V 11.1V 22.2V 11.1V 22.2V
reset Protection Against over
Discharge by reconnecting the load -
Status LeD “bATT” goes back to
Green from red
12.6V 25.2V 12.6V 25.2V 12.6V 25.2V
Discharging Limit Voltage 10.8V 21.6V 10.8V 21.6V 10.8V 21.6V
SeCtIOn 6 | Specifications
