24 | SAMLEX AMERICA INC. SAMLEX AMERICA INC. | 25
SeCtIOn 6 | Specifications
ParaMeter SPeCIFICatIOn
CharGe COntrOller
Type Series Type, PWM control
PWM frequency 25 Hz
battery System Voltage
12V / 24V Nominal; Auto Sensing
(<18V sensed as 12V / >18V sensed as 24V)
rated battery Current 10A
operating Voltage range of battery 6V to 36V
Min. battery Voltage to Start Controller 6V
Charge Circuit Voltage Drop ≤ 0.26V
Discharge Circuit Voltage Drop ≤ 0.15V
Self Consumption ≤ 6mA
Temperature Compensation
(with built-in Temperature Sensor)
Temperature Coefficient of Voltage
of Temperature Sensor:
• -30mV / °C for 12V battery
• -60mV / °C for 24V battery
InPut – PV Panel(S) / array
Maximum open Circuit Voltage, Voc 50V
Maximum Short Circuit Current, Isc 10A
InPut / OutPut COnneCtIOnS
Type of connectors Moving Cage Type for 6mm 2 / AWG #10 wire size
PrOteCtIOnS
overheating: Status LeDs “Sealed”, “Gel”
& “flooded” flash simultaneously
Cuts off input and output if heat sink
temperature is >85°C.
Auto reset when temperature drops to below 75°C
reverse / battery reverse Polarity Controller will not be damaged
Short Circuit / overload on Load Terminals Load is disconnected
Short Circuit in PV Panel(s) Controller will not be damaged
enVIrOnMental
operating Temperature -35°C to +55°C
Storage Temperature -35°C to +80°C
Humidity 10% to 90% Non Condensing
Ingress Protection (IP) rating of enclosure IP-30 (NoT water proof)
MeChanICal
overall Dimensions 140 x 65 x 34mm / 5.51 x 2.56 x1.34 in
Mounting Dimensions / Mounting Holes 130 x 45 mm (5.12 x 1.77 in) / 4.5 mm Diameter
Weight 0.15 kg / 0.33 lbs
bATTeRy CHARGING & bATTeRy PRoTeCTIoNS (At Reference Temperature of 25°C)
