SeCtIOn 3 |
Installation
figure 3.5 System wiring review
Step 5: Install fuse
Install 10A fuse in each fuse holder in the following order:
1. battery circuit
2. Load circuit
Step 6: Confirm Power on
When battery power is applied and the controller starts up, the battery Status LeD
“bATT” (3, fig 2.1) will be GreeN.
If the controller doesn't start up, or the battery Status LeD error exists, please refer to
Section 5 for Troubleshooting.
battery
1
2
3
fuse - 10A
fuse -
10A
