20 | SAMLEX AMERICA INC.
SeCtIOn 4 | Operation
LeD coLoR & PAtteRn StAtUS
Green - Steady “noRMAL”: battery is in bulk Stage - Normal State of Charge of
up to 80%
Green - Slowly flashing “FULL”: battery is in either Absorption (boost) or equalization or
float Stage and PWM regulated voltage charging is active. State
of Charge is nearly full / completely full - 80% to 100%
orange - Steady “UnDeR VoLtAGe”: battery Under Voltage Warning Signaling
has been activated at ≤ 12V / ≤ 24V. output is still available at
Load Terminals
- Will be reset automatically when voltage rises to 12.2V / 24.4V
and LeD will go back to steady Green from steady orange
red - Steady “oVeR DiScHARGe”: Protection against over discharge of bat-
tery has been activated at ≤ 11.1V / ≤ 22.2V and the load has
been disconnected.
- Load will be reconnected automatically at 12.6V / 25.2V and
the LeD will go back to steady Green from steady red
4. StAtUS LeD “FLooDeD”: flooded type of battery has been selected
5. StAtUS LeD “GeL”: Sealed, Gel Cell type of battery gas been selected.
6. StAtUS LeD “SeALeD”: Sealed, AGM type of battery has been selected.
7. StAtUS LeD “LoAD” LoAD StAtUS inDicAtoR: Display the load status.
LeD coLoR & PAtteRn StAtUS
red - flashing
red - Steady
oVeR LoAD oR SHoRt ciRcUit”: Load has been disconnected
due to overload or short circuit in the load circuit connected to
the Load Terminals
- overload: 12.5A for 5 sec – Manual reset by pressing “Set”
button
- Short Circuit: 35A – first short circuit is reset automatically
after 10 sec. Second consecutive short circuit will require
manual reset by pressing “Set” button
Load in oN condition
overheating Protection Indication
LeD coLoR & PAtteRn StAtUS
Status LeDs “Sealed” (6), “Gel” (5)
and “flooded” (4)
flashing red simultaneously Heat sink of the controller > 85°C
Input and output circuits have been disconnected
Will reset automatically when temperature drops
to < 75°C
