37 Command Summary
2.12 Touch
12.1 Create A
Touch Region Dec
Hex
ASCII 254 132
FE 84
þ „
Index X Y Width Height Up Down
Index X Y Width Height Up Down
Index X Y Width Height Up Down 2.0
Create a region of the screen that responds to touch events with a defined single byte and visual update.
Index Byte Index used to identify the desired touch region.
X Signed Short Leftmost coordinate of the touch region.
Y Signed Short Topmost coordinate of the touch region.
Width Short Width of the touch region.
Height Short Height of the touch region.
Up Byte Index of a loaded bitmap that is displayed when the region is released.
Down Byte Index of a loaded bitmap that is displayed when the region is touched.
12.2 Clear A
Touch Region Dec
Hex
ASCII 254 133
FE 85
þ …
Index
Index
Index 2.0
Clear the specified touch region entry from memory and screen, ensuring its events will no longer be reported.
Index Byte Index used to identify the desired touch region.
12.3 Clear All
Touch Regions Dec
Hex
ASCII 254 134
FE 86
þ †
2.0
Clear all touch regions, ensuring their touch events will no longer be reported.
12.4 Change
Touch Reporting
Style Dec
Hex
ASCII 254 135
FE 87
þ ‡
ReportingType
ReportingType
ReportingType 2.0
Customize the way in which touch events are reported. Default is Region Down.
ReportingType Byte Desired touch reporting style, as per eTouchReportingType values.
Table 29: eTouchReportingType values
Value Description Value Description
0 Region None 8 Coord None
1 Region Down 9 Coord Down
2 Region Up 10 Coord Up
3 Region Up/Down 11 Coord Up/Down
4 Region Move 12 Coord Move
5 Region Move/Down 13 Coord Move/Down
6 Region Move/Up 14 Coord Move/Up
7 Region Move/Up/Down 15 Coord Move/Up/Down
