33 Command Summary
Table 26: eTraceTypeandDirection values
Value Description
0 Bar
1 Line
2 Step
3 Box
0 Bottom Left
16 Left Up
32 Top Right
48 Right Down
64 Bottom Right
80 Left Down
96 Top Left
112 Right Up
0 Shift Toward Origin
128 Shift Away From Origin
10.11 Update a
Trace Dec
Hex
ASCII 254 117
FE 75
þ u
Index Value
Index Value
Index Value 2.1
Update the value of the trace at the specified index. Trace will be bounded to the minimum and maximum.
Index Byte Index used to identify the desired trace. Specific to Traces.
Value Signed Short Current value of the trace index to be updated.
10.12 Update
Multiple Traces Dec
Hex
ASCII 254 118
FE 76
þ v
Index Length Values
Index Length Values
Index Length Values 2.1
Simultaneously update the values of numerous traces, useful for updating a multi-variable graph.
Index Byte Index used to identify the first desired trace. Specific to Traces.
Length Byte Number of trace values to be set.
Values Signed Short(s) Current values, one for each of the trace index to be updated.
Return Message 252 118 Length Result
Result Byte Outcome of Update Multiple Traces command, as pereErrorCode values.
10.13 Clear All
Traces Dec
Hex
ASCII 254 119
FE 77
þ w
2.1
Clear all trace entries from buffer memory, erasing all attributes and images, then setting all to an unused state.
