Matrix Orbital GTT70A - Manual (Page 38)

Command Summary 34
10.14 Set Trace
Min/Max Dec
Hex
ASCII 254 148
FE
þ
Index Min Max
Index Min Max
Index Min Max 2.2
Update the min and max values of the specified trace. Trace will update to new minimum and maximum values.
Index Byte Index used to identify the previously defined trace. Specific to Traces.
Min Signed Short Minimum value for the specified trace.
Max Signed Short Maximum value for the specified trace.
10.15 Get Trace
Min/Max Dec
Hex
ASCII 254 149
FE
þ
Index
Index
Index 2.2
Get the current min and max values of the specified trace.
Index Byte Index used to identify the previously defined trace. Specific to Traces.
Return Message 252 149 Length Min Max
Min Signed Short Current minimum value for the specified trace.
Max Signed Short Current maximum value for the specified trace.
