17 Command Summary
4.19 Draw
Rounded
Rectangle Dec
Hex
ASCII 254 127
FE 7F
þ •
X Y Width Height Radius
X Y Width Height Radius
X Y Width Height Radius 2.0
Draw a rectangular frame one pixel wide with rounded corners using the current drawing colour. The radius must
be equal to or less than half the length of the smallest side of the rectangle.
X Signed Short Leftmost coordinate of the rectangle
Y Signed Short Topmost coordinate of the rectangle
Width Signed Short Width of the rectangle.
Height Signed Short Height of the rectangle.
Radius Short Radius of the rounded corners.
4.20 Draw Filled
Rounded
Rectangle Dec
Hex
ASCII 254 128
FE 80
þ €
X Y Width Height Radius
X Y Width Height Radius
X Y Width Height Radius 2.0
Draw a filled rectangle with rounded corners using the current drawing colour. The radius must be equal to or less
than half the length of the smallest side of the rectangle.
X Signed Short Leftmost coordinate of the rectangle
Y Signed Short Topmost coordinate of the rectangle
Width Signed Short Width of the rectangle.
Height Signed Short Height of the rectangle.
Radius Short Radius of the rounded corners.
4.21 Draw
Triangle Dec
Hex
ASCII 254 129
FE 81
þ •
X1 Y1 X2 Y2 X3 Y3
X1 Y1 X2 Y2 X3 Y3
X1 Y1 X2 Y2 X3 Y3 2.0
Draw a triangular frame one pixel wide using the current drawing colour.
X1 Signed Short Horizontal coordinate of the first point.
Y1 Signed Short Vertical coordinate of the first point.
X2 Signed Short Horizontal coordinate of the second point.
Y2 Signed Short Vertical coordinate of the second point.
X3 Signed Short Horizontal coordinate of the third point.
Y3 Signed Short Vertical coordinate of the third point.
4.22 Draw Filled
Triangle Dec
Hex
ASCII 254 130
FE 82
þ ‚
X1 Y1 X2 Y2 X3 Y3
X1 Y1 X2 Y2 X3 Y3
X1 Y1 X2 Y2 X3 Y3 2.0
Draw a filled triangle using the current drawing colour.
X1 Signed Short Horizontal coordinate of the first point.
Y1 Signed Short Vertical coordinate of the first point.
X2 Signed Short Horizontal coordinate of the second point.
Y2 Signed Short Vertical coordinate of the second point.
X3 Signed Short Horizontal coordinate of the third point.
Y3 Signed Short Vertical coordinate of the third point.
