Matrix Orbital GTT70A - Manual (Page 32)

Command Summary 28
2.9 Animations
9.1 Set Up
Animation Dec
Hex
ASCII 254 193
FE C1
ю Б
Index Instance X Y
Index Instance X Y
Index Instance X Y 2.0
Define a region of the screen to be used to display a loaded animation. If an animation is already in use at that
index it will be overwritten. Use the start animation command to display and play the file.
Index Byte Index used to identify the desired file in the animation buffer.
Instance Byte Index used to identify the state of a specific animation instance.
X Signed Short Leftmost coordinate.
Y Signed Short Topmost coordinate.
9.2 Start/Stop
Animation Dec
Hex
ASCII 254 194
FE C2
ю В
Instance State
Instance State
Instance State 2.0
Start or stop a specific animation. After it is started, an animation will loop until stopped.
Instance Byte Index of a previously defined Animation instance to be started/stopped.
State Byte Desired animation state, as per eAnimationState values.
Table 23: eAnimationState values
Value Description
0 Paused
1 Playing
9.3 Set
Animation
Frame Dec
Hex
ASCII 254 195
FE C3
ю Г
Instance Frame
Instance Frame
Instance Frame 2.0
Set the current frame of a displayed animation. If the frame exceeds the total number present, the animation will
be set to the first frame.
Instance Byte Index of a previously defined Animation instance whose frame will be changed.
Frame Byte Number of the frame to be displayed.
9.4 Get
Animation
Frame Dec
Hex
ASCII 254 196
FE C4
ю Д
Instance
Instance
Instance 2.0
Read the current frame of the specified animation instance.
Instance Byte Animation instance upon which the current frame query will be carried out.
Return Message 252 196 Length Frame
Frame Byte Current animation frame.
